Details on Pump Selection

Pump selection

You are here:

Module Overview ➤ Scheme Heating/Potable Water ➤ Component data... ➤ (Context menu of the component)

Applies to: Heating and Potable Water.

Select a manufacturer pump and assign the data to the pump.

Manufacturer

Here you can select all manufacturers whose data sets have been installed and if necessary licensed.

Series

Here all series are available, that are contained in the selected manufacturer data set.

Pump

Here, all models of the selected series are available.

Diagram

The graph shows the characteristics of the selected model.

Data sheet

If the manufacturer provides a data sheet in the data set, you can view it here.

Assign

Use this command to assign manufacturer data to a pump, which are used for calculation and in the material lists.
