V22 Out now!
The Project and Design Tool
Your workflow is optimally supported by the direct integration into CAD without interfaces. Construct detailed designs with minimal effort. Further, your detail drawings become exact at the push of a button with the original liNear manufacturer libraries. You may thus generate ready-to-order materials lists.
Pipe and Air Duct Network Calculations
- directly in the model! For more than 20 years, liNear's graphical network calculations have been in tough practical use and have proven their worth. It is exact calculations, short design times, clear and comprehensible results as well as complete bills of quantities which make the programs so efficient that they are used even in the design departments of our industrial partners, whether on AutoCAD, Revit, or CADinside.
Load Calculations and Dimensioning
By making use of construction material tables and integrated U-value calculation, the concept of global variables and your own project templates, you may reduce the time for the energetic analysis of the building to an absolute minimum. A detailed dimensioning of system components such as radiators or panel heating and cooling systems on the basis of actual products leads to complete parts lists for the creation of bills of quantities. In this respect, the task planning helps to document implementation instructions, building progress, and also defects where they belong: in the existing building structure.
Intuitive 3D Design
Whether pipe constructions, air duct systems, steel constructions or electric cable trays are concerned, with the help of the object-oriented modules of the liNear Design 3D family and tens of thousands of audited three-dimensional components from our industrial partners you may create your systems accurately and fast. You will be enthused about the ease of 3D construction with liNear Design 3D – practical and including all the details. What you see is what you get!
